THE TRANSMISSION GALLERY

Bilsdale mk1 North Yorkshire
NGR: SE553962 Maps: Google  Bing (Ord Surv)   Site Height: 379.1m      Structure Height: 314.6m
Digital TV:

National Radio:
Local Radio:
Digital Radio:

Comments: The original Bilsdale mast was built during 1968/9 and entered service with BBC 2 on 24-Nov-1969. On the 10-Aug-2021 a fire broke out
within the mast taking all services off-air. The mast was subsequently deemed structurally unsound and was demolished on 6-Oct-2021.

Bilsdale mk2 North Yorkshire
NGR: SE553962 Maps: Google  Bing (Ord Surv)   Site Height: 379m      Structure Height: 306.2m
Digital TV: BBC A: 27   D3&4: 24   BBC B: 21   SDN: 43   Arq A: 46   Arq B: 40
  Local Mux: 30
National Radio: Radio 1: 98.6   Radio 2: 89.0   Radio 3: 91.2   Radio 4: 93.4   Classic FM: 101.6
Local Radio: Capital FM (North East): 106.4   Heart FM (North East): 100.7   Hits Radio (Teesside): 96.6   BBC Tees: 95.0
Digital Radio: BBC National: 12B   Digital One: 11D   North Yorkshire: 10C   Sound Digital: 11A   Teesside: 11B
Comments: New mast built to replace original demolished mast. Service date 22-May-2023 TV, 23-Jan-2024 radio.

Bilsdale Quarry North Yorkshire
NGR: SE550959 Maps: Google  Bing (Ord Surv)   Site Height: 375m      Structure Height: 80m
Digital TV:

National Radio:
Local Radio:
Digital Radio:
Comments: Temporary mast that provided services while a more substantial temporary tower was constructed. Service dates 13 October 2021 to 23 February 2022. The mast has now been removed.

Bilsdale Tower North Yorkshire
NGR: SE553962 Maps: Google  Bing (Ord Surv)   Site Height: 379m      Structure Height: 77.65m
Digital TV:

National Radio:
Local Radio:
Digital Radio:
Comments: Temporary tower to provide services while a new mast is built to replace the original demolished mast. Service date 23 February 2022

Show historic services



Photos from mid 1980s
Photos by TCPD

March 2003
Photos by Don Burluraux


Photos by Dan Licke

August 2012 - pre DSO.
Photos by Peter C

August 2015
Photos by Martin Brown

Local TV added - August 2017
Photos by Martin Brown

Bilsdale Fire
Photos by Various

Bilsdale Quarry temporary mast - November 2021
Photos by Martin Brown

Bilsdale Tower - January 2022
Photos by Martin Brown

The aftermath - January 2022
Photos by Martin Brown

March 2022
Photos by Martin Brown

Reconstruction update - May 2022
Photos by Martin Brown

Reconstruction update - August 2022
Photos by Martin Brown

The new mast rises - October 2022
Photos by Martin Brown

February 2023
Photos by Martin Brown

The replacement mast at full height - May 2023
Photos by Martin Brown

September 2023
Photos by Martin Brown

Bilsdale fire 1975
Photos by John Rhodes

May 2024
Photos by Martin Brown

Coverage area map
UHF Post-DSO Digital TV

Coverage area map
BBC Tees
